Versatile signage projector
Compact, unobtrusive, ultra-short-throw design for tight spaces
SKU: V11HA83180
EB-775F
Best for professional environments. 4,100-lumen Full HD 3LCD projector for versatile business and education use.
- Up to 150-inch display
- 4,100 lumens brightness
- Built-in WiFi & Miracast
Features
Create engaging displays
Up to 150" Full HD displays, 4,100 lumens and 3LCD technology
Fit and forget reliability
Low maintenance laser projector with a 5 year warranty
Flexible playback
Play content directly from a USB stick
Specifications
- Projector Colour
- Black
- Heat Dissipation
- 895 BTUperhour
- Loudspeaker
- 16 W
- Noise Level -Normal
- 37 dB (A)
- Noise Level -Economy
- 27 dB (A)
- Options
- Wall mount
- Positioning
- Ceiling Mounted, Desktop, Wall Mounted
- Power consumption -(Normal On-Mode)
- 200 W
- Power consumption- (Eco On-Mode)
- 141 W
- Power consumption -(Normal Peak-mode)
- 263 W
- Power consumption -(Eco Peak-Mode)
- 199 W
- Power consumption - (Energy saving standby)
- 0.5 W
- Product Dimensions
- 356 x 395 x 133 mm (Width x Depth x Height)
- Product Range
- E9
- Room Type / Application
- Signage / Retail, Visitor Attraction
- Single Unit
- ZN
- Supply Voltage
- 220 V - 240 V, 50 Hz - 60 Hz
- Supported Humidity - Operation (from)
- 20 %
- Supported Humidity - Operation (to)
- 80 %
- Supported Humidity - Storage (from)
- 10 %
- Supported Humidity - Storage (to)
- 90 %
- Supported Temperature - Operation (from)
- 0
- Supported Temperature - Operation (to)
- 40
- Supported Temperature - Storage (from)
- -10 °C
- Supported Temperature - Storage (to)
- 60 °C
- TCO Certified
- Yes
- LCD Panel (Type)
- 0.61 inches with
- LCD Panel
- C2 Fine
- Projection System
- 3LCD Technology, RGB liquid crystal shutter
- Resolution
- 1080p
- Android TV
- No
- Epson iProjection App
- Ad-Hoc / Infrastructure
- Google TV
- No
- Included Software
- Epson Creative Projection, EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management
- Network Protocol
- IPv6, PJLink, ESC/VP.net, SNMP, HTTPS
- Network Protocol (Projector)
- IPv6, PJLink, ESC/VP.net, SNMP, HTTPS
- Other features
- A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, Customizable user logo, Digital zoom, Direct Power on/off, Edge Blending, Document Camera Compatible, Email notification, Horizontal and vertical keystone correction, Image Shift, JPEG Viewer, Long light source life, OSD copy function, Network projection, PC Free, Power on button, Quick Corner, Schedule Function, Screen Mirroring, Web Control, Web Remote, Wireless LAN capable, iProjection App, Ultra-wide display (16:6), Home Screen, 21:9 aspect ratio support, CEC compatible
- Projector control
- Crestron Integrated Partner, Crestron RoomView, Extron IP Link, Control4 Simple Device Discovery Protocol, AMX Device Discovery
- Sealed Light Source Module - Yes
- No
- Sealed Light Source Module - IP5X rated
- n/a
- Sealed Optical Engine - Yes
- No
- Sealed Optical Engine - IP5X rated
- n/a
- Security (Visual product)
- Kensington lock, Padlock, Security cable hole, Wireless LAN unit lock, Password protection, Wireless LAN security, Control panel lock
- Video Colour Modes
- Dynamic, Cinema, Presentation, sRGB, DICOM SIM, Multi Projection, Blackboard
- Colour Light Output - Lumens
- 4100 Lumens
- Colour Light Output - Luman (economy) in accodance with
- 2800 Lumens
- Colour Light Output Testing Standard
- In accordance with ISO 21118:2012
- Colour Reproduction (Projector)
- Upto 1.07 billion colours
- Colour Video Processing
- 10 Bits Color
- Contrast Ratio - Ratio:1
- 5000000
- Contrast Ratio - Absolute black
- Absolute black
- High Definition
- Full HD
- Keystone Correction Type (Horizontal)
- manual
- Keystone Correction Angle (Horizontal)
- 3
- Keystone Correction Type (Vertical)
- manual
- Keystone Correction Angle (Vertical)
- 3
- Laser Lightsource -Durability High
- 20000 hr
- Laser Lightsource -Durability Eco
- 30000 hr
- Light Source (Visual product)
- Laser
- White Light Output - Lumens
- 2800 Lumens
- White Light Output - Lumens (economy) in accodance with
- 2800 Lumens
- White Light Output Testing Standard
- In accordance with ISO 21118:2020
- Interchangeable Lens
- No
- Lens
- Optical
- Lens (varies by lens)
- n/a
- Lens Shift (varies by lens)
- n/a
- Mechanical shutter
- No
- Offset
- 5
- Offset - varies by lens
- n/a
- Projection Distance from
- 0.7 m
- Projection Distance screen size
- 120 inch screen
- Projection Distance varies by lens
- n/a
- Projection Distance Wide from
- 0.4 m
- Projection Distance Wide screen size
- 65 inch screen
- Projection Distance Wide varies by lens
- n/a
- Projection Distance Wide Tele varies by lens
- n/a
- Projection Lens F Number to
- 1.6
- Projection Lens F Number varies by lens
- n/a
- Projection Lens Focal Length (To)
- 3.7 mm
- Projection Lens Focal Length (varies by lens)
- n/a
- Projection Lens Focus
- Manual
- Projection Lens Focus (varies by lens)
- n/a
- Screen Size from
- 60 in
- Screen Size to
- 150 in
- Screen Size varies by lens
- n/a
- Throw Ratio from
- 0.25
- Throw Ratio to
- 0.35
- Type of Zoom
- motorized
- Zoom factor (from)
- 1
- Zoom factor (to)
- 1.35
- Power cable
- Remote control incl. batteries
- User guide
- Warranty Documents
- Quick Start Guide
